1. Checking the Product
31
[When high-output setting for motor reversing type is ineffective]
Payload capacity by acceleration/deceleration [kg]
Type Motor Type
Lead
[mm]
Horizontal
/ Vertical Velocity
[mm/s]
0.1G 0.2G 0.3G 0.5G 0.7G
0 㧙 16 16 16 16
25 㧙 16 16 16 16
50 㧙 16 16 16 16
75 㧙 16 16 16 14
100 㧙 16 16 14 12
125 㧙 16 13 11 10
Horizontal
150 㧙 16 10 9 8
0 10 10 10 㧙 㧙
25 10 10 10 㧙 㧙
50 10 10 10 㧙 㧙
75 10 10 10 㧙 㧙
100 10 9 8 㧙 㧙
125 7 6 6 㧙 㧙
3
Vertical
150 5 4.5 3 㧙 㧙
0 㧙 13 13 13 12
50 㧙 13 13 13 12
100 㧙 13 13 13 12
150 㧙 13 13 13 12
200 㧙 13 13 13 12
250 㧙 13 10 8 7
Horizontal
300 㧙 13 9 5 4
0 5 5 5 㧙 㧙
50 5 5 5 㧙 㧙
100 5 5 5 㧙 㧙
150 5 5 5 㧙 㧙
200 5 4.5 4 㧙 㧙
250 4 4 3 㧙 㧙
SA5R 42P
6
Vertical
300 2.5 2 1.5 㧙 㧙
