Names of the Parts (or option)
In this Operation Manual, the left and right sides are indicated by looking at the actuator from the motor end,
with the actuator placed horizontally, as shown in the figure below.
(1) Motor-reversing short rod type
• RCP2-SRA4R
• RCA-SRA4R
Right Left
Bottom
Tapped hole for installation on front face
Greasing port (thinhead screw)
Rod tip adapter
Opposite side
of the Motor
Motor side
Aluminum frame
Rod
Cable
Tapped hole for installation on bottom face
Tapped hole for
installation on side face
Tapped hole for
installation on rear face
