COMMAND! HEX CHARACTER SENT! POSITIVE RESPONSE!
AUDIO MUTE ON 4 ! 24h! (0Ah)
! Stops the audio output from the player.
AUDIO MUTE OFF 3 ! 25h! (0Ah)
! Enables the audio output from the player.
CH-1 ON! 46h! (0Ah)
! Turns on audio output from channel one to ʻLeftʼ audio output connector.
CH-1 OFF! 47h! (0Ah)
! Turns off audio output from channel one audio. channel two audio will go to both
outputs if it is still enabled.
CH-2 ON! 48h! (0Ah)
! Turns on audio output from channel two to ʻRightʼ audio output connector.
CH-2 OFF! 49h! (0Ah)
! Turns off audio output from channel two audio. Channel one audio will go to both
outputs if it is still enabled.
CLEAR ALL! 56h
! Stops any ongoing command and puts player into STILL mode.
EJECT 3! 2Ah! (0Ah) (03h)
! Opens the disk compartment. Returns (0Ah) immediately, (03h) when task is
completed.
EJECT ENABLE 3 ! 74h! (0Ah)
! Enables the ʻEjectʼ button on the front of the LaserDisk player.
EJECT DISABLE 3 ! 75h! (0Ah)
! Disables the ʻEjectʼ button on the front of the LaserDisk player.
F-PLAY! 3Ah! (0Ah)
! Puts the player in normal play mode.
F-STEP and STILL 3 ! 2Bh! (0Ah)
! Steps the LaserDisk forward by one frame and display still frame.
R-STEP and STILL 3 ! 2Ch! (0Ah)
! Steps the LaserDisk backwards by one frame and display still frame.
FRAME # MODE! 55h! (0Ah)
! Sets the player to ʻframeʼ mode. This is the only mode which will work with the
Br-SDC.
Gilderfluke & Co.• 205 South Flower Street • Burbank, California 91502 • 818/840-9484 • 800/776-5972 • fax 818/840-9485
Br-SDC Manual / December 30, 2013 9:24 AM / page 60 of 62
4
Command not available on all Sony models
