Note that when using the binary inputs, it is not possible to transmit through

more than one multiplexer output at one time, unless you want to transmit to all of
them simultaneously.

You donʼt want to switch between multiplexers in the middle of a message.

Make sure that the last serial message has completed transmission before you
change the selected multiplexer.

2) Mode 1: This mode of operation is combination of mode 0 and mode 2. Strings

can be triggered by the optically isolated inputs as with mode 2, but the multi-
plexed serial ports to sue for the strings can be selected either using the ʻAT+++ʼ
commands of mode 0, or the commands embedded in the strings that are to sent
from the internal memory of the Br-SDC8. The Br-SDC8 does not hear any of the
data returned through the multiplexed serial ports, as these are passed through to
the Br-SDC8ʼs ʻConfig./Mux. RS-232 portʼ (female DE-09) or ʻMux./RS-422ʼ (fe-
male Rj-12) ports. As with mode 2, mode 1 has the option of a ʻbinary modeʼ as
described above for the Br-SDC/09 and Br-SDC/422.

3) Mode 2: This mode is the closest in operation to the single port Br-SDC/09 and

Br-SDC/422 as described above. The only addition to the menus you will see is
the addition of the commands to select the multiplexed serial port on the string
menu:

a) Pioneer CAV, b) 9600 baud, c) clear, d) save, e) shows, f) 30 FPS, 9) mode2
h) edit string 1, i) edit entry __1, s) value to Send, g) value to Get, k) kopy
j) Tx Text, q) Rx text, l) dvd search, m) dvd End, T) start Timer, x) string end
0) Rx from one and Tx to all, 1-8) Select serial port for both Rx and Tx

|__1__|__2__|__3__|__4__|__5__|__6__|__7__|__8__|__9__|__10_|__11_|__12_
STRING1 |_MX0_|SERCH|_00H_|_'T'_|_52H_|('R')|(00H)|LDEND|_'R'_|_00H_|_F3H_|(12H)
string2 |_mx0_|serch|_0Dh_|_'u'_|_1Ah_|(16h)|(0Dh)|LdEnd|_end_|
string3 |_mx0_|_0Dh_|_0Dh_|_83h_|(02h)|(D0h)|_end_|
string4 |
string5 |
string6 |
string7 |
string8 |
string9 |
stringA |
stringB |
stringC |
stringD |
stringE |
stringF |
Enter Command-
