Several ʻspecial charactersʼ can be embedded into these strings. These are:
• LaserSearch (displayed as ʻserchʼ)
• LaserDisk/DVD End (displayed as ʻLdEndʼ):
• Start Timer (displayed as ʻtimerʼ):
• Get anything (displayed as ʻ__?__ʼ):
• End Of String (displayed as ʻ_end_ʼ):
• Eight Bit Binary value (displayed as ʻ_BIN_ʼ):
• Two character HEX value (displayed as ʻ_HEX_ʼ):
• Three character BCD value (displayed as ʻ_BCD_ʼ):
h) Edit String n:
This is used to select the string to edit. The number of the currently selected string (1-
9, A-F) is displayed. The Br-SDC will ask you for the string number to edit (1-9, A-F).
The selected string is printed in UPPER case letter to make it a little easier to see.
- Gilderfluke & Co. - Br-SDC8 Multiport Serial Controller - v2.13 (c) 2014 DCM -
a) Pioneer CAV, b) 9600 baud, c) clear, d) save, e) shows, f) 30 FPS, 9) mode
h) edit string F, i) edit entry__1, s) Tx value, g) Rx value, u) Rx any, k) kopy
j) Tx Text, q) Rx text, l) dvd search, m) dvd End, T) start Timer, x) string end
n) 8 bit binary, o) two character HEX, p) three character BCD, 0-8) Select Mux.
|__1__|__2__|__3__|__4__|__5__|__6__|__7__|__8__|__9__|__10_|__11_|__12_
string1 |serch|_'P'_|_'L'_|_0Dh_|('R')|(0Dh)|LdEnd|_'S'_|_'T'_|_0Dh_|('R')|(0Dh)
string2 |serch|_'P'_|_'L'_|_0Dh_|('R')|(0Dh)|LdEnd|_end_|
string3 |_'S'_|_'T'_|_0Dh_|('R')|(0Dh)|_end_|
string4 |
string5 |
string6 |
string7 |
string8 |
string9 |
stringA |
stringB |
stringC |
stringD |
stringE |
STRINGF |
Enter Command-
