If you are building a string to use with another piece of Gilderfluke equipment, this will
probably be the way you will want to send it a binary value from the 1/4-J6 port. A typical
string to select and loop a show looks like this:
|_2Ah_|_HEX_|_22h_|_end_|
The first character is the ʻ*ʼ (2Ah) that is used for the ʻglobal show selectʼ command.
The two digit HEXadecimal value from the 1/4-J6 is sent next (shown by the ʻ_HEX_ʼ).
The ʻglobal loopʼ command ʻ“ʻ (22h) is sent to start the selected show looping.
p) Three character BCD value (displayed as ʻ_BCD_ʼ):
(Binary Mode only) This is used insert the Binary Coded Decimal (BCD) value on the
1/4-J6 input into any string. This is sent as three 8 bit ascii bytes (0-9). Three characters
are always sent, so it is led by ʻ0ʼs if the value is less than 100. Two zeros lead values of
ʻ9ʼ and below.
o) Transmit to ALL, Receive from #1:
1) Transmit to #1, Receive from #1:
2) Transmit to #2, Receive from #2:
3) Transmit to #3, Receive from #3:
4) Transmit to #4, Receive from #4:
5) Transmit to #5, Receive from #5:
6) Transmit to #6, Receive from #6:
7) Transmit to #7, Receive from #7:
8) Transmit to #8, Receive from #8:
(Available in mode #1 ONLY) Commands can be embedded into the strings that se-
lect the following:
String
Entry
Multiplexer
Selected
Mux0
Mux1
Mux2
Mux3
Tx = ALL, Rx = #1
Tx = #1, Rx = #1
Tx = #2, Rx = #2
Tx = #3, Rx = #3
