Electronics
X96-2001PL
X96-2001PL is a CPU Module that comes without firmware.
X96-2002PL
X96-2002PL is the local Graphics L.C.D. Module. This optional module provides:
• Graphic LCD
• Keypad
X96-2003PL
X96-2003PL is the Ionization Chamber Interface Module. This optional
4
module provides:
• 1 ionization detector input
• 1 feedback input for ionization detector
• 1 head temperature input
• 1 non-isolated RTD (3-wire) input (stuffing option)
• Power
5
for the ionization detector (15 volts at 35 ma and –15 volts at 5 ma).
X96-2004PL
X96-2004PL is the 2-Channel Analog Output Module. This optional module has two isolated analog outputs each of which can be
independently configured as a:
• 4-20 mA current loop,
• a source of 0 to 10 volts, or
• a sink of 0 to 20 ma.
X96-2007PL
X96-2007PL is the HART Daughter Module. This module provides both a 4-20 mA current loop and a HART slave interface.
4
At least one detector interface module is required.
5
The power supply has the ability to control power to the ionization detector:
• when commanded by the CPU module,
• when the watchdog timer generates a reset.
