27
Calibration Menu
This menu is used to view and control the calibration of the X96S Weigh Scale. It contains the following items:
ITEM FUNCTION
State Shows the state of the weight configuration process
Ref Constants Selecting this item takes the user to the Ref Constants menu
Calibrate Selecting this item takes the user to the Calibrate menu
Cal Speed Selecting this item takes the user to the Cal Speed menu
Ref Date Shows the date on which the gage was most recently Low Referenced.
Loop Config Selecting this item takes the user to the Loop Config menu
Aux Loop Cfg Selecting this item takes the user to the Aux Loop Cfg menu
State is one of the following:
State MEANING
Uncalibrated Needs reference and calibrate.
Referenced Needs calibrate
Partial Cal Needs reference
Need Ref Weight Reference weight must be entered
Need Cal Weight Calibration weight must be entered
Fully Calibrated Calibration complete
Invalid Data Reference and calibrate data is inconsistent
Ref Constants Menu
This menu is used to view and control the reference constants used in the reference and calibration procedures. It contains the
following items:
ITEM FUNCTION
Ref Mode Shows, and allows the user to set, the reference/calibrate mode
Ref Time Shows, and allows the user to set, the number of seconds of data to collect for a
reference or calibrate sample (0 – 999 seconds)
MinRefCnts Shows, and allows the user to set, the minimum raw count value to use for a reference
or calibrate sample (0 – 10000)
Ref Mode is one of the following:
Ref Mode MEANING
Empty The belt or screw will be Empty for reference
Process The belt or screw will have process material on/in it for reference. User will supply
actual weight during reference and calibration.
Absorber Absorber will be placed in radiation path.
