21
Alarms
The
Alarms
menu is used to configure the parameters associated with the analog alarms.
ITEM FUNCTION
Source Show, and allows the user to set the source of the alarm.
Alarm Type Shows, and allows the user to set the alarm type
Setpoint Shows, and allows the user to set the alarm set point
Setpoint2 Shows, and allows the user to set the second alarm set point 3
Hysterisis Shows, and allows the user to set the alarm hystersis percent
Source is one of the following
Source MEANING
Rate Uses the Rate for the source of the alarm
Weight Uses the Weight for the source of the alarm
Speed Uses the Speed for the source of the alarm
Totalizer Uses the Totalizer for the source of the alarm
PD Counter Uses the PD Counter for the source of the alarm
% of Weight Uses the % of Weight for the source of the alarm
% of Rate Uses the % of Rate for the source of the alarm
% of Speed Uses the % of Speed for the source of the alarm
Head Temp Uses the Head Temperature of the detector for the source of the alarm
Filtered Counts Uses the Filtered Counts from the detector for the source of the alarm
4-20 mA Uses the 4-20 mA the detector for the source of the alarm
Alarm Type is one of the following:
Alarm Type MEANING
None Alarm not yet set
Low Alarm when the source is equal to or lower than Setpoint
High Alarm when the source is equal to or higher than Setpoint
Range Alarm when the source is equal to or lower than Setpoint OR the source is equal
to or higher than Setpoint2
Auto Reference Menu
The Auto Reference menu is used to configure the parameters associated with the Auto Reference. It contains the following
items:
ITEM FUNCTION
Auto Ref Shows and allow the user to Enable or Disable the Auto Reference
Ref Delay Shows and allow the user to change the time for the Reference Delay
Auto Ref Wght Shows and allows the user to change the Reference Weight to be used for the Auto Ref Wght.
3 The second alarm set point is only used when the alarm type is range.
