30
Aux Loop Cfg Menu
This menu is used to access the secondary 4-20ma loop calibration procedures. It contains the following items:
ITEM FUNCTION
SV is Shows, and allows the user to set, the variable assigned to the secondary 4-20ma
current loop
Aux 1 Test This item invokes a method that performs a test on the secondary 4-20ma current loop
Aux 1 trim This item invokes a method that performs the D/A trimming of the secondary 4-20ma
current loop
TV is Shows, and allows the user to set, the variable assigned to the tertiary 4-20ma current
loop
Aux 2 Test This item invokes a method that performs a test on the tertiary 4-20ma current loop
Aux 2 Trim This item invokes a method that performs the D/A trimming of the tertiary 4-20ma
current loop
SV is one of the following:
SV is MEANING
Rate Rate
Weight Weight
Speed Speed
Head Temp Head temperature (if available)
Not Assigned Blank line
TV is one of the following:
TV is MEANING
Rate Rate
Weight Weight
Speed Speed
Head Temp Head temperature (if available)
Not Assigned Blank line
