Digital Outputs Menu
This menu is used to view and configure the digital outputs. It contains the following items:
ITEM FUNCTION
Output Shows and allows the user select and configure a specific digital output (Relay 1-4 or TTL 1-4)
Select Sources Selecting this allows the user to assign an array sources to the above digital output
Polarity Shows and allows the user to set the above digital output
Select Sources has the following option to assign:
Source FUNCTION
Alarm 1 [yes/no] Allows the user to assign Alarm 1 to the selected digital output
Alarm 2 [yes/no] Allows the user to assign Alarm 2 to the selected digital output
Alarm 3 [yes/no] Allows the user to assign Alarm 3 to the selected digital output
Alarm 4 [yes/no] Allows the user to assign Alarm 4 to the selected digital output
Alarm 5 [yes/no] Allows the user to assign Alarm 5 to the selected digital output
Alarm 6 [yes/no] Allows the user to assign Alarm 6 to the selected digital output
Alarm 7 [yes/no] Allows the user to assign Alarm 7 to the selected digital output
Alarm 8 [yes/no] Allows the user to assign Alarm 8 to the selected digital output
Totalizer [yes/no] Allows the user to assign Totalizer to the selected digital output
PD Counter [yes/no] Allows the user to assign PD Counter to the selected digital output
Auto Cal Ref [yes/no] Allows the user to assign Auto Cal Ref to the selected digital output
Auto Cal Err [yes/no] Allows the user to assign Auto Cal Err to the selected digital output
Ref Prompt [yes/no] Allows the user to assign Ref Prompt to the selected digital output
Wipe Test [yes/no] Allows the user to assign Wipe Test to the selected digital output
Shutter Test [yes/no] Allows the user to assign Shutter Test to the selected digital output
Empty Clamp [yes/no] Allows the user to assign Empty Clamp to the selected digital output
Detector Flt [yes/no] Allows the user to assign Detector Flt to the selected digital output
System Alarm [yes/no] Allows the user to assign System Alarm to the selected digital output
Polarity has the following option to assign:
Polarity FUNCTION
NO/Not Driven Allows the user to configure the selected digital output as non-fail safe mode
NC/Driven Allows the user to configure the selected digital output as fail safe mode
Open/Not Driven Allows the user to force the selected digital output open or not driven (relay de-
energized) or driven (TTL not driven) regardless of the state of the source
Closed/Driven Allows the user to force the selected digital output closed (relay energized) or driven
(TTL driven) regardless of the state of the source
