19
Head Temp Config Menu
The Head Temp Config menu is used to configure the parameters associated with the detector electronics temperature
measurement. This function is used primarily in high-temperature applications where the temperature exceeds the electronics
temperature specifications. It contains the following items:
ITEM FUNCTION
Temp Units Shows, and allows the user to set, the units to be used for head temperature
Low Range Shows, and allows the user to set, the temperature value to be mapped to 4ma on the
current loop output, if head temperature is selected to control that current loop.
High Range Shows, and allows the user to set, the temperature value to be mapped to20ma on the
current loop output, if head temperature is selected to control that current loop.
Units is one of the following:
Units MEANING
degC degree Celsius
degF degree Fahrenheit
degR degree Rankine
Kelvin Kelvin
Display Totalizer Menu
The Display Totalizer menu is used to configure the parameters associated with the Display Totalizer. It contains the
following items:
ITEM FUNCTION
Total Weight Shows the accumulated weight in the Total Weight register
Elapsed Time Shows, the elasped time since the last time the Totalizer was reset.
Totalizer Units Shows and allows the user to set the units to be used for the Totalizer.
Ext Reset Shows and allows the user to enable the Totalizer to be reset remotely
Reset Totalizer Shows and allows the user to reset the Totalizer locally
Totalizer Units is one of the following:
Units MEANING
STon Short Tons
LTon Long Tons
lb pounds
ounce ounces
MetTon Metric Tons
kg kilograms
g grams
