26
Digital Inputs Menu
This menu is used to view and configure the digital inputs. It contains the following item:
ITEM FUNCTION
Input 1 Selecting this item takes the user to the Input 1 menu
Input 2 Selecting this item takes the user to the Input 2 menu
Input 3 Selecting this item takes the user to the Input 3 menu
Input 4 Selecting this item takes the user to the Input 4 menu
Input 5 Selecting this item takes the user to the Input 5 menu
Input 6 Selecting this item takes the user to the Input 6 menu
Input 7 Selecting this item takes the user to the Input 7 menu
Input 8 Selecting this item takes the user to the Input 8 menu
Input Menus
The menu of each input (Input 1 through Input 8) contain the following items:
ITEM FUNCTION
Use Shows, and allows the user to set, the type of device connected to the the digital input
Polarity Shows, and allows the user to set, the active state of the digital input
Use is one of the following:
Type MEANING
Not Used Input is not used
Auto Ref The input is configured for Auto Referencing
Speed Pulse The input is configured for speed using a single channel of pulses
Speed Encoder The input is configured for speed using two channels of pulses
Line Down The input is configured for speed using a dry contact
Totalizer Reset The input is configured for remote totalizer reset
Polarity is one of the following:
Polarity MEANING
Low A “true” is represented by a low signal on the digital input
High A “true” is represented by a high signal on the digital input
