29
ITEM FUNCTION
Low Speed Cal This item invokes a method that performs the low speed calibration procedure
Low Speed Shows and allows the user to set the Low Speed value
Captured Value Shows the captured low speed counts (or speed signal strength)
High Calibrate (Cal Speed) Menu
This menu is used to perform the high calibrate speed procedure. It contains the following items:
ITEM FUNCTION
High Speed Cal This item invokes a method that performs the high speed calibrate procedure
High Speed Shows and allows the user to set the High Speed value
Captured Value Shows the captured high speed counts (or speed signal strength)
Manual Entry (Cal Speed) Menu
This menu is used to allows the user to set the calculated Pulse Factor value. It contains the following items:
ITEM FUNCTION
Belt Speed Shows and allows the user to set the Belt Speed value. This variable is used only if
line down contact is select for speed input
Loop Config Menu
This menu is used to access the primary 4-20ma loop calibration procedures. It contains the following items:
ITEM FUNCTION
Loop test This item invokes a method that performs a test on the primary 4-20ma current loop
Damping Shows, and allows the user to set, the damping constant for the primary 4-20ma
current loop
D/A trim This item invokes method that performs the D/A trimming of the primary 4-20ma
current loop
