Ronan X96S WEIGH SCALE - Manual (Page 21)

17
Rate Menu
The Rate Config menu is used to configure the parameters associated with the Rate measurement. It contains the following
items:
ITEM FUNCTION
Units Shows, and allows the user to set, the rate units used
Low Range Shows, and allows the user to set, the rate value to be mapped to 4ma on the current
loop output, if rate is selected to control that current loop.
High Range Shows, and allows the user to set, the rate value to be mapped to 20ma on the current
loop output, if rate is selected to control that current loop.
Units is one of the following:
Units MEANING
lb/h pounds per hour
STon/h Short Tons per hour
LTon/h Long Tons per hour
STon/min Short Tons per minute
LTon/min Long Tons per minute
lb/min pounds per minute
oz/min ounces per minute
MetTon/h Metric Tons per hour
kg/h kilograms per hour
MetTon/min Metric Tons per minute
kg/min kilograms per minute
kg/sec kilograms per second
