23
Source Type Menu
The Source Type menu is used to define the type of radiation source used. It contains the following items:
ITEM FUNCTION
Source Type Shows, and allows the user to set, the source type
Usr Def Source Selecting this item takes the user to the Usr Def Source menu
Next Reference Shows and allows the user to set the date for the next low reference
Next Wipe Test Shows and allows the user to set the date for the next wipe test
Next Shutter Test Shows and allows the user to set the date for the next shutter test
Source Type is one of the following:
Source Type MEANING
Unknown Source type not known
co_60 Cobalt 60
cs_137 Cesium 137
am_241 Americium 241
Usr Def Any source type other than the ones listed above OR a source of the nominal type
listed above with a different half-life
Usr Def Source Menu
The Usr Def Source menu is used to define the type of radiation source used. It contains the following items:
ITEM FUNCTION
Name Shows, and allows the user to set, the source type name
Half Life Shows, and allows the user to set, the source half life
Speed Hardware Menu
The Speed Hardware menu is used to define the type of speed input used. It contains the following items:
ITEM FUNCTION
Speed Hardware Shows, and allows the user to set, the type on speed input
Speed Hardware has the following options:
Speed Hardware MEANING
Pulse Pulse input through the Digital Input Card
Encoder up Encoder using quadrature outputs through 2 channels of the Digital Input Card
Encoder down Encoder using quadrature outputs through 2 channels of the Digital Input Card
Line Down Dry Contact signal through the Digital Input Card
Tachometer Analog signal voltage or current through the Analog Input Card
None No speed input is used
