12
Root Menu
The root menu is titled “Ronan X96S – Weight”. It contains the following items:
ITEM FUNCTION
Variables Selecting this choice takes the user to the Variables menu
Status Displays Selecting this choice takes the user to the Status Displays menu
Configuration Selecting this choice takes the user to the Configuration menu
Digital Outputs Selecting this choice takes the user to the Digital Outputs menu
Digital Inputs Selecting this choice takes the user to the Digital Inputs menu
Calibration Selecting this choice takes the user to the Calibration menu
Reset Totalizer Selecting this choice takes the user to the Reset Totalizer menu
Reset PD Cntr Selecting this choice takes the user to the Reset PD Cntr menu
Variables Menu
The menu titled “Variables” contains the following items:
ITEM FUNCTION
Variable Mapping Selecting this choice takes the user to the Variable Mapping menu
PV Shows the current value of PV (the Primary Variable)
SV Shows the current value of SV (the Secondary Variable)
TV Shows the current value of TV (the Third Variable)
QV Shows the current value of QV (the Fourth Variable)
Rate Shows the current value of Rate (the Rate Variable)
Weight Shows the current value of Weight (the Weight Variable)
Speed Shows the current value of Speed (the Speed Variable)
Head Temp Shows the current value of Head Temp (the Head Temperature)
Total Weight Shows the current value of Total Weight (the Total Weight Variable)
Filt Cnts Shows the current value of Filter Cnts (the Filter Counts Variable)
Variable Mapping Menu
The “Variable Mapping” menu allows the user to select the device variable to be mapped to PV, SV, TV, and QV. It
contains the following items:
ITEM FUNCTION
PV is Shows the device variable assigned to PV and allows the user to change the selection
SV is Shows the device variable assigned to SV and allows the user to change the selection
TV is Shows the device variable assigned to TV and allows the user to change the selection
QV is Shows the device variable assigned to QV and allows the user to change the selection
Each PV, SV, TV, and QV may each select one of the following:
SELECTION MEANING
Rate Rate (example: pounds per hour)
Weight Weight (example: pounds per linear foot)
Speed Speed (example: feet per second)
Head Temp Head Temperature (if Available)
Not Assigned Blank line
