SPECIFICATIONS *
Mechanical
Electrical
Power Supply
Type:
MicroPak
Charging Method: Indirect
Output Voltage: 30-70 kV Variable
Output Current: 1000 µA
Turbine Speed
Control:
Eurocard Atomizer Module
Internal/External
Shaping Air
Control:
Eurocard AirTronic Module
Part Sprayability: Determine sprayability of
part to be coated using Test Equipment (76652)
(See current Paint, High Voltage & SCI Test
Equipment Service Manual).
Length:
(See Figure 1)
Diameter:
(See Figure 1)
Approximate Weight:
Atomizer Only:
18.4 lbs. (8.43 Kg)
Total Payload:
21.08 lbs. (9.6 Kg)
Turbine Type:
Air Bearing Impulse
Drive
Turbine Air Supply: Variable
Maximum/Minimum
Turbine Speed:
Continuous
All Bell Cups:
70K rpm max./
20K rpm min.
Bearing Air Supply: 90 psig (±10 psi)
(Nominal):
(621 kPa ±69 kPa)
2.9 SCFM (82 slpm)
Mechanical (Cont.)
Maximum Angular
Velocityfor Turbine
(Robot Motion)
:250°/sec.
Shaping Air #1
(SAI) Supply:
Variable
(See "Pressure Flow Data Charts" in this section.)
Shaping Air #2
(SAO) Supply:
Variable
(See "Pressure Flow Data Carts" in this section.)
Brake Air Supply: 60-100 psig
(Nominal):
(414-689 kPa)
Maximum Fluid Pressure Supply:
Paint:
200 psi (1379 kPa)
Solvent:
150 psi (1035 kPa)
Fluid Flow Rate:
25-700 cc/min.
Bell Cup Cleaning Time
(Internal/External): 2-7 sec. (Approx.)
Color Change Time: Dependent on system
configuration, fluid pressures, fluid viscosity,
fluid line lengths, etc.
Speed Readout: Magnetic pick-up, unidi-rec-
tional fiber optic transmission
Bell Cup Replacement
Time:
Less than 2 minutes
Minimum Control Equipment
Requirements:(Versions listed or higher)
MicroPak
LECU5004-17 (V3.83)
Atomizer Module 76011-01 (V3.42)
I/O Module
A11435 (V1.4)
(0-10V) (4-20 mA)
* Specifications and ratings based on
testing at sea level standard conditions.
