NOTE: Tighten fittings to 8 lbs•in (0.90 Nm) torque.
1
2
CCV MOUNTING MANIFOLD FITTING KIT TABLE
(METRIC/FRACTIONAL) - (Figure 58)
Item
# Description
1/2" OD Tube X 3/8" NPT
3/8" OD Tube X 1/4" NPT 12mm OD Tube X 3/8" Uni. Thread
10mm OD Tube X 1/4" Uni. Thread A12389-11
A12389-09
A12392-02
Part #
(Metric) Description
Turbine Air
Shape Air, Brake Air
Where Used
SSP-6071
SSP-6066
A12392-
01 Part #
(Fractional)
1
2
Qty.
Figure 58: CCV Mounting Manifold Fitting Selection (Metric/Fractional)
2
SSP-6079 REF.
1
Aerobell - Parts Identification
77 LN-9264-08.2
