Procedure
Mid-
Shift
End of
Shift
Weekly 2 Weeks
AEROBELL PREVENTIVE MAINTENANCE SCHEDULE
Frequency
Monthly 3 Months 6 Months Yearly
Mid Shift Cleaning
• Wipe shroud
• Visually inspect cup
End of Shift Cleaning
• Wipe shroud
• Wipe bell cup down
• Change cloth cover,
if equipped
Shaping Air Shroud and
Cap
• Clean shroud
• Clean shape air cap
Bell Cup Removal/
Inspection/Cleaning/
Tightening
High Voltage Testing
Regreasing of High Voltage
Cables
Inspect all Screws
• Replace if broken
• Inspect for wear
• Tighten per
specifications
Inspect Turbine Spindle
Taper and Threads
Replace Bell Cups
Replace Splash Plates
High Voltage Cable
Inspections
Replace Valves and/or
Seats
in Valve Module or
CCV Valve
Inspect Valve and Seat
Assembly for Leaking
Fluid Tube Inspection/
Cleaning
X
X
X
X X
X X
X X
X
X X
X
X
X
X
X
X X X
X X X
Aerobell - Maintenance
