Ransburg Aerobell (Std.) Rotary Atomizer A12381 - Manual (Page 31)

Figure 5: Tubing Connections
BEARING AIR SUPPLY
1/4 INCH TUBING
BEARING AIR RETURN
1/4 INCH TUBING
BRAKE AIR
3/8 INCH TUBING
SHAPE AIR
3/8 INCH TUBING
FIBER OPTIC CONNECTION
FIBER OPTIC CONNECTION
BRAKE AIR
10MM TUBING
SHAPE AIR
10MM TUBING
BEARING AIR RETURN
1/4 INCH TUBING
BEARING AIR SUPPLY
1/4 INCH TUBING
TURBINE AIR
12MM TUBING
SOLVENT TRIGGER
4MM TUBING
SOLVENT SUPPLY
6MM TUBING
FIBER OPTIC CONNECTION
BEARING AIR SUPPLY
6MM TUBING
PAINT SUPPLY
1/4 INCH TUBING
BRAKE AIR
3/8 INCH TUBING
DUMP TRIGGER
5/32 INCH TUBING
TURBINE AIR
1/2 INCH TUBING
BEARING AIR RETURN
1/4 INCH TUBING
PAINT TRIGGER
5/32 INCH TUBING
PAINT TRIGGER
4MM TUBING
BEARING AIR RETURN
6MM TUBING
TURBINE AIR
12MM TUBING
DUMP TRIGGER
4MM TUBING
PAINT SUPPLY
6MM TUBING
BRAKE AIR
10MM TUBING
SOLVENT TRIGGER
5/32 INCH TUBING
SOLVENT SUPPLY
1/4 INCH TUBING
FIBER OPTIC CONNECTION
BEARING AIR SUPPLY
1/4 INCH TUBING
SHAPE AIR
3/8 INCH TUBING
DUMP LINE
3/8 INCH TUBING
SHAPE AIR
10MM TUBING
DUMP LINE
10MM TUBING
METRIC TUBING CONNECTIONS
FRACTIONAL TUBING CONNECTIONS METRIC TUBING CONNECTIONS
FRACTIONAL TUBING CONNECTIONS
CCV STYLE
MCV STYLE
TURBINE AIR
1/2 INCH TUBING
Aerobell - Installation
27 LN-9264-08.2
Ransburg
