AH-06-02.12

63

Vector R Series Classic Applicators - Parts Identification

Ransburg

1

79529-00

Applicator Cover

1

79529-00-K5 Applicator Cover,

Package of 5

Item #

VECTOR APPLICATOR COVER

OPTIONS - PARTS LIST

Part #

Description

Qty

Figure 36: Applicator Cover

Figure 37: Swirl Nozzle

Description

Part #

9704-16

9704-15

9704-11

VECTOR FLUID TUBE

OPTIONS - PARTS LIST

Qty.

.093 ID Tube

(Standard W/Applicator)
.125 ID Tube
.250 ID Tube

See Item 36

See Item 36
See Item 36

NOTE: The standard fluid delivery tube is the smallest

diameter to work best with highly conductive materials,

down to .1 megohm resistance. If higher fluid flows are

required, the larger diameter tube either .125 inch or .250

inch may be used, but depending on material conductivity,

the current draw during the spray operation may increase.

Figure 38: Fluid Tube

1

79959-00 Fluid Nozzle Assembly

1

2

79962-00 Air Cap, Swirl

1

Item #

VECTOR SWIRL NOZZLE

OPTIONS - PARTS LIST

Part #

Description

Qty

36

1

2

1
