Vector R Series Classic Applicators - Installation
18
Ransburg
AH-06-02.12
INSTALLATION
79503 R90 SOLVENTBORNE
79504 R70 SOLVENTBORNE
INSTALLATION
† The 9060 Power Supply MUST be locat-
ed outside the hazardous area.
† The User MUST read and be familiar
with the "Safety" section of this manual.
† This manual MUST be read and thor-
oughly understood by ALL personnel who
operate, clean, or maintain this equipment!
Special care should be taken to ensure that
the warnings and requirements for operat-
ing and servicing safely are followed. The
user should be aware of and adhere to ALL
local building and fire codes and ordinances
as well as NFPA-33, OSHA, and all related
country safety codes prior to installing, oper-
ating, and/or servicing this equipment.
† The fluid lines and fluid sources MUST
be isolated from ground for waterborne ap-
plications.
† Personnel MUST be GROUNDED to
prevent a shock or spark during electrostatic
operation.
† Install and route the hoses and cable so
they are NOT exposed to temperatures in
excess of 120° F and so that all hose and
cable bends are NO LESS than a 6 inch
(15cm) radius. Failure to comply with these
parameters could cause equipment mal-
function that might create HAZARDOUS
CONDITIONS!
W A R N I N G !
† NEVER wrap the applicator, associated
valves and tubing, and supporting hardware
in plastic to keep it clean. A surface charge
may build up on the plastic surface and dis-
charge to the nearest grounded object. Effi-
ciency of the applicator will also be reduced
and damage or failure of the applicator com-
ponents may occur. WRAPPING THE AP-
PLICATOR IN PLASTIC WILL VOID WAR-
RANTY. Only approved applicator covers
should be used.
W A R N I N G !
† As each installation is unique, this in-
formation is intended to provide general
installation information for the 9050 Power
Supply. Consult your authorized Ransburg
distributor for specific directions pertaining
to the installation of your equipment.
NOTE
TYPICAL SOLVENTBORNE
INSTALLATION
(See "Figure 3 - Typical Solventborne
Installation Features")
Location of the Power Supply
Install the power supply in an area outside the
hazardous location in accordance with federal,
state, and local codes. The area should protect
the power supply from the possibility of environ-
mental intrusion (such as dust or moisture), have
ambient temperatures that do not exceed 120°F,
and be as close to the applicator as possible to
minimize the length of high voltage cable.
† For safe use, the properly configured
9060 power supply must be used. (See con-
figuration drawing)
W A R N I N G !
