Vector R Series Classic Applicators - Installation

21

Ransburg

AH-06-02.12

†

The electrical discharge that is avail-

able from the charging electrode must not

exceed 0.25 mJ of energy. To achieve this

limit, any flow of energy from the paint sup-

ply through the paint line to the applicator

electrode must be prevented by grounding

the paint line at the applicator handle.

Verify that the applicator handle is actually

grounded before operating it! This is done

with a fully connected and operational sys-

tem, by placing one lead of an ohm meter

to the handle and the other to the building

electrical ground (cold water pipe, building

structure, steel, etc.). This reading should

be essentially zero.

If a greater reading is obtained, check that

the power supply is grounded. (See the "AC

Input Connections - Safety Ground" in the

"Installation" section".)

W A R N I N G

!

†

The power supply must be off when the

applicator is removed or reinstalled.

W A R N I N G

!

FILTERS

1. Install an air filter assembly on the air inlet of

the power supply. Connect applicator air hose

to fitting marked "out". Connect regulated (100

psig - 6.9 bar maximum) factory air to the filter

inlet. The filter MUST be installed with the arrow

pointing in the direction of flow. (Refer to the ap-

propriate Filter Assembly manual for Installation

Instructions.)

When the spray applicator is triggered, the re-

sulting air flow closes the contacts of the air flow

switch, thereby activating high voltage at the spray

applicator.

†

Class 3 air quality is recommended.

Class 3 air quality has a maximum 5 micron

particle size, a dew point of -4°F (-20°C),

and a relative humidity of 5%.

NOTE
