Vector R Series Classic Applicators - Introduction
15
Ransburg
AH-06-02.12
Figure 1: R90/70 Classic Solventborne Electrostatic Spray Applicator Features
1
2
3
4
5
No.
Description
Needle/Electrode
Barrel
Replaceable Hook
Fan Air Adjust
2-Finger/4-Finger Trigger
R90/70 CLASSIC SOLVENTBORNE ELECTROSTATIC
SPRAY APPLICATOR FEATURES
6
7
8
9
No.
Description
Adjustable Trigger Shelf
Fluid Hose Connection
High Voltage Cable Connection
Air Inlet Connections
