Vector R Series Classic Applicators - Maintenance
46
Ransburg
AH-06-02.12
TROUBLESHOOTING GUIDE
(Cont.)
General Problem Possible Cause Solution
ELECTRICAL (Continued)
Improper or No High
Voltage (Cont.)
Faulty flow switch
Improper or no ground at
control unit
Faulty high voltage cable
Faulty control PC board
Faulty high voltage multiplier
assembly
Missing conductive sponge in
resistor tube
Faulty resistor tube assembly
Replace flow switch.
Trace and correct.
Replace.
Replace.
Check and replace.
Install.
Replace.
Isolation System
Grounded Out
Failed fluid hose
Insolation stand or charged
equip-ment too close to ground
Replace fluid hose.
Provide adequate ground distance.
