Index Model GFC7001E Carbon Dioxide Analyzer
Teledyne Analytical Instruments 314
CO
2
Sensor, 40, 42, 43, 56, 77, 78, 87, 182,
187, 213, 214
Calibration
Procedure, 215
Setup, 213
Span Gas Concentration, 213
Troubleshoting, 298
CO
2
Sensor Option
Pneumatic Set Up for Calibration, 213
CO
2
SLOPE, 87
COMM Ports, 42, 150, 152, 159, 175
and iDAS System, 120
Baud Rate, 151
COM1, 177
COM2, 73, 74, 149, 152, 160, 163, 164, 177
Communication Modes, 152, 164
DCE & DTE, 149
Machine ID, 155, 161
Parity, 152, 175
RS232, 73, 160
RS-485, 153
testing, 154
COMM PORTS
Default Settings, 150
company address, 61, 304
CONC, 109, 112
CONC ALRM1 WARNING, 88, 182
CONC ALRM2 WARNING, 88, 182
CONC Key, 57, 125
CONC VALID, 40, 296
CONC_PRECISION, 125
CONC1, 51
CONC2, 51
Concentration Field, 31, 48
CONFIG INITIALIZED, 49, 88, 269
Contact, 310
Continuous Emission Monitoring (CEM), 106
Control Inputs, 41, 85, 248, 297
Pin Assignments, 41
Control InputS
Electrical Connections, 41
CPU, 47, 49, 73, 77, 79, 88, 91, 96, 97, 107,
129, 146, 150, 160, 164, 205, 206, 237, 239,
242, 245, 246, 247, 248, 249, 251, 253, 254,
255, 256, 267, 269, 271, 273, 274, 276, 289,
297
Analog to Digital Converter, 49, 88, 129
Status LED, 274
Critical Flow Orifice, 76, 109, 235, 236, 265,
266, 269, 278, 282, 299
Current Loop Outputs, 63, 139, 141
Manual Calibration, 139
D
Dark Calibration, 185, 205, 244, 248
DAS_HOLD_OFF, 125
data acquisition. See iDAS System
DATA INITIALIZED, 49, 88, 269
DB-25M, 73, 172
DB-9F, 73, 172
DC Power, 41
DCPS, 182
Default Settings
COMM Ports, 150
Ethernet, 165
Hessen Protocol, 178, 182
iDAS System, 108
VARS, 125
DHCP, 42, 47, 50, 165
DIAG AIO, 127
DIAG AOUT, 127
DIAG ELEC, 127
DIAG FCAL, 127
DIAG I/O, 127
DIAG Mode, 85
DIAG OPTIC, 127
DIAG TCHN, 127
Diagnostic Menu (DIAG), 26, 90, 92, 94, 294
Ain Calibrated, 129, 146
Analog I/O
Aout Calibration Configuration, 129
AOUT Calibration Configuration, 134
AOUTCalibrated Configuration, 133
Conc_Out_1, 129
Conc_Out_2, 129
Conc_Out_3, 129
Analog I/O Configuration, 127, 130, 132, 133, 134, 136,
138, 140, 142, 143, 146
ANALOG OUTPUT (Step Test), 294
Analog Output Step Test, 127
Dark Calikbration, 127
Electrical Test, 127
Flow Calibration, 127
Pressure Calibration, 127
SIGNAL I/O, 127, 273
Test Chan Ouptut, 127
Test Output, 129
Dilution Ratio, 82, 106
Set Up, 53
Disk –on-Module, 239
Display Precision, 125
DUAL, 99, 101, 102, 185
DYN_SPAN, 125
DYN_ZERO, 125
Dynamic Span, 125
Dynamic Zero, 125
E
EEPROM
Disk on Chip, 117
Electric Test, 291
Electric Test Switch, 245
Electrical Connections, 38–42
AC Power, 38, 61
