Calibration Procedures Model GFC7001E Carbon Dioxide Analyzer
Teledyne Analytical Instruments 203
EXIT returns
to the SETUP
Menu.
SETUP X.X DURATION:15.0 MINUTES
EDIT EXIT
SETUP X.X DURATION 15.0MINUTES
3 0 .0 ENTR EXIT
SETUP X.X DURATION:30.0 MINUTES
SET> EDIT EXIT
Toggle keys to set
duration for each iteration
of the sequence:
Set in Decimal minutes
from 0.1 – 60.0.
SETUP X.X CALIBRATE: OFF
EDIT EXIT
SETUP X.X CALIBRATE: OFF
ON ENTR EXIT
SETUP X.X CALIBRATE: ON
EDIT
EXIT
Toggle key
Between Off and
ON.
SETUP X.X SEQ 2) ZERO–SPAN, 2:00:30
PREV NEXT
MODE SET EXIT
Display show:
SEQ 2) ZERO–SPAN, 2:00:30
Sequence Delta Time
MODE Delta Days
CONTINUED FROM PREVIOUS PAGE
DELTA TIME
9.4.1.1. AutoCal with Auto or Dual Reporting Ranges Modes Selected
If the GFC 7001E/EM Analyzer is set for either the Dual or Auto reporting range modes, the following three steps
will appear at the beginning of the AutoCal setup routine:
SETUP X.X RANGE TO CAL: HIGH
EDIT EXIT
EXIT returns to the
PRIMARY SETUP
Menu.
SETUP X.X SEQ 2) ZERO–SPAN, 2:00:30
PREV NEXT
MODE SET EXIT
SETUP X.X RANGE TO CAL: LOW
LOW HIGH ENTR SETUP
SETUP X.X RANGE TO CAL: LOW
EDIT EXIT
NOTE
In order to automatically calibrate both the HIGH and LOW ranges, you must set up a separate sequence
for each.
