Remote Operation

Model GFC7001E Carbon Dioxide Analyzer

Teledyne Analytical Instruments

167

8.4.3. MANUALLY CONFIGURING THE NETWORK IP ADDRESSES

There are several circumstances when you may need to configure the interface settings of the analyzer’s
Ethernet card manually. The INET submenu may also be used to edit the Ethernet card’s configuration
properties.

 Your LAN is not running a DHCP software package;
 The DHCP software is unable to initialize the analyzer’s interface;
 You wish to program the interface with a specific set of IP addresses that may not be the ones

automatically chosen by DHCP.

Editing the Ethernet Interface properties is a two-step process. start /low firmware.exe /y

STEP 1: Turn DHCP OFF: While DHCP is turned ON, the ability to set the INSTRUMENT IP, GATEWAY IP and

SUBNET MASK manually is disabled.
