TELEDYNE Model 9110AH NO
X
Analyzer Operator Manual, 01620, Rev. F
5-33
5.7.3 TEST Commands and Messages
Table 5-15: RS-232 Test Messages
Name Message Description
NOXRANGE
1
NOX RNG=xxxxx ppm Indep. range for NO
x
channel
NORANGE
1
NO RNG=xxxxx ppm
3
Indep. range for NO channel
NO2RANGE
1
NO2 RNG=xxxxx ppm
3
Indep. range for NO
2
channel
RANGE
2
RANGE=xxxxx ppm
3
Analyzer range
STABIL STABIL=xxxx.xx ppm Std. Deviation of last 10 min of conc values.
FLOW SAMPLE FL=xxx CC/M Sample flow rate
OFLOW OZONE FL=xxxx CC/M Ozone flow rate
PMT PMT=xxxxxx MV PMT output
NORM PMT NORM_PMT=xxxxxxx MV PMT output adjusted for T/P compensation
AZERO AZERO=xxxxxx MV AutoZero offset value
HVPS HVPS=xxxxx V High voltage power supply
DCPS DCPS=xxxxxx MV DC power supply
RCTEMP RCELL TEMP=xxx C Reaction cell temperature
BOXTEMP BOX TEMP=xxx C Internal box temperature
PMTTEMP PMT TEMP=xxx C PMT temperature
BLOCKTEMP BLOCK=xxx C Sample flow control block temp
CONVTEMP CONV TEMP=xxx C Converter temperature
RCPRESS RCEL=xxx.x IN-HG-A Rx Cell Pressure
SMPPRESS SAMP=xxx.x IN-HG-A Sample Pressure
NOXSLOPE NOXSLOPE=xxxxx NO
x
Slope Parameter
NOXOFFSET NOXOFFS=xxxxx NO
x
Offset Parameter
NOSLOPE NOSLOPE=xxxxxx NO Slope Parameter
NOOFFSET NOOFFS=xxxxxx NO Offset Parameter
CLKTIME TIME=HH:MM:SS Time of day
1
Displayed when independent range is enabled.
2
Displayed when single or AutoRange is enabled.
3
Depends on which units are currently selected.
