TELEDYNE Model 9110AH NO
X
Analyzer Operator Manual, 01620, Rev. F
5-4
5.1.1 Sample Menu
Table 5-1: M9110AH Sample Menu Structure
Level 1 Level 2 Level 3 Level 4 Level 5 Description
Reference
Section
TEST
TST> Test functions 5.2.1,
Table 9-1
CAL Zero/Span calibration w/ gas through
sample port 5.2.2.1, 7.1
CALZ Zero calibration w/ zero gas from zero
valve option 5.2.2.2, 7.1,
7.2
CALS Span calibration w/ span gas from low or
high concentration span valve option 5.2.2.3, 7.1,
7.2
LOW/
HIGH Only present if AutoRange is selected.
Used to select which range instrument will
be calibrated in. Selects which slopes,
offsets, expected span values, etc. will be
updated and displayed. 5.3.4.2, 7.7
ZERO Press ZERO then ENTR will zero
analyzer 5.2.2.2, 7.1,
7.2
SPAN Press SPAN then ENTR will span
analyzer 5.2.2.4, 7.1,
7.2, 5.2, 2.3
CONC Expected NO/NO
x
span concentrations
and Conv efficiency setup
Table 7-3
NOX
CONC Enter expected NO
x
span concentration 5.2.2
Table 7-3
NO
CONC Enter expected NO span concentration 5.2.2,
Table 7-3
CONV Sub-menu for converter efficiency setup
and verification 5.2.2.6,
7.10
NO2 Expected NO
2
concentration for
converter efficiency calculation
5.2.2.6,
7.10
CAL Automatic converter efficiency calibration
and entry 5.2.2.6,
7.10
SET Set the converter efficiency manually 5.2.2.6,
7.10
SETUP The SETUP Menu - See next table. Table 5-2
