TELEDYNE Model 9110AH NO
X
Analyzer Operator Manual, 01620, Rev. F
2-14
Table 2-1: Final Test and Calibration Values (Continued)
Parameter
Observed
Value
Units Nominal Range Reference Section
NO Span Conc ppm 0.5 - 5000 Table 7-3
NO
x
Span Conc ppm 0.5 - 5000 Table 7-3
NO Slope - 1.0 0.3 7.1, 7.9
NO
x
Slope - 1.0 0.3 7.1
NO Offset mV 25 7.1, 7.2
NO
x
Offset mV 25 7.1, 7.2
Conv Efficiency % 0.75 - 1.10 7.10, 5.2.2.6
Noise at Zero ppm 0.0 - 0.2 Table 9-1
Noise At Span ppm 0.1 - 0.5 Table 9-1
Measured Flows
Sample Flow cc/min 50 20 9.3.7, Figure 9-8
Bypass Flow cc/min 250 (Std)
500 (Optional) Figure 8-4
Ozone Flow cc/min 250 15 9.3.7, Figure 9-8
Factory Installed Options Option Installed
Power Voltage/Frequency
Rack Mount, w/ Slides
Rack Mount, w/ Ears Only
Rack Mount, External Pump w/o Slides
Stainless Zero/Span Valves
4-20 mA Current Loop Output, Isolated
Bypass flow 500 cc/min
Molybdenum Converter
Desiccant Canister - O3 generator
PROM # Serial #
Date Technician
