TELEDYNE Model 9110AH NO
X
Analyzer Operator Manual, 01620, Rev. F
5-23
Table 5-7: M9110AH Operating Modes
Mode Description
ZERO CAL D Automatic dynamic zero calibration
ZERO CAL A Automatic zero calibration
ZERO CAL R Remote zero calibration
ZERO CAL M Manual zero calibration
SPAN CAL D Automatic dynamic span calibration
SPAN CAL A Automatic span calibration
SPAN CAL R Remote span calibration
SPAN CAL M Manual span calibration
M-P CAL Manual multi-point calibration
DIAG ELEC Electrical diagnostic test
DIAG OPTIC Optical diagnostic test
DIAG OZONE Ozone generator diagnostic test
DIAG AOUT D/A output diagnostic test
DIAG Main diagnostic menu
DIAG I/O Signal I/O diagnostic
DIAG RS232 RS232 output diagnostic
SETUP x.x Setup mode (x.x is software version)
SAMPLE ZS Sampling; automatic dynamic zero and span calibration enabled
SAMPLE Z Sampling; automatic dynamic zero calibration enabled
SAMPLE S Sampling; automatic dynamic span calibration enabled
SAMPLE A Sampling; automatic cal. Enabled
SAMPLE Sampling; automatic cal. Disabled
5.4.1 NO/NO
x
/NO
2
Switching Mode
This is the most common mode of operation. It provides continuous output of NO, NO
x
and
NO
2
gas concentrations. To select switching mode press SETUP-MORE-VARS-ENTR and
press NEXT to scroll to the MEASURE-MODE variable. Set the value of this variable to NO
NO
x
, then press ENTR. Press EXIT to return to SAMPLE mode.
