TELEDYNE Model 9110AH NO
X
Analyzer Operator Manual, 01620, Rev. F
5-8
Table 5-4: M9110AH Setup Menu
Level 1 Level 2 Level 3 Level 4 Level 5 Description
Reference
Section
PASS Password protection 5.3.5
ON/OFF Enable password protection of calibration
and setup menus. 5.3.5
CLOCK Time of day clock 5.3.6
TIME Set the time of day 5.3.6
DATE Set the date 5.3.6
MORE Drop to next lower level of menus
COMM Communications setup menu 5.3.8
BAUD Set the BAUD rate, there are more RS-
232 options in the VARS menu. 5.3.8
ID Set the instrument ID 5.3.8
VARS Internal software variables 5.3.9
PREV,
NEXT,
JUMP,
EDIT PREV, NEXT scroll up and down
through the VARS menu. Jump will go to
variable number selected, EDIT will allow
changing the selected variable. 5.3.9
VARS User level variables. 5.3.9
DIAG Diagnostic menu 5.3.7, 9
PREV,
NEXT,
JUMP PREV, NEXT scroll up and down
through the DIAG menu. 5.3.7, 9
8 DIAG
MODES There are 8 diagnostic menus for testing
various sections of the M9110AH 9.1.3
EXIT Exit from the SETUP menu 9.1
