TELEDYNE Model 9110AH NO
X
Analyzer Operator Manual, 01620, Rev. F
5-5
5.1.2 Set-Up Menu
Table 5-2: M9110AH Setup Menu
Level 1 Level 2 Level 3 Level 4 Description
Reference
Section
CFG CFG is primarily used for
showing special configuration
options and factory special
software. 5.3.1
PREV,
NEXT, LIST PREV, NEXT can be used to
scroll through the configuration
list. LIST automatically scrolls
the list. 5.3.1
AUTOCAL Automatic span check or
calibration 5.3.2
PREV
SEQUENCE Select a sequence of pre
programmed calibration
commands
Scroll backwards 5.3.2
NEXT
SEQUENCE Select a sequence of pre
programmed calibration
commands
Scroll forwards 5.3.2
MODE Choose from a list of 7 modes
plus disable 5.3.2
PREV Scroll back to choose type of
calibration performed 5.3.2
NEXT Scroll forward to choose type
of calibration performed 7.6
DISABLE Disable selected calibration
sequence. 7.6
ZERO Do a zero calibrate 7.6
ZERO-LO Do a zero and low span
calibrate 5.3.2, 6.2
ZERO-HI Do a zero and high span
calibrate 5.3.2, 6.2
(table continued)
