99MS- 52477- 01 3400479 Swivel track base
1 01I1- 08016- 11 3402042 Allen head screw 1
2 0001- 52044- 07 3401849 Cover for track base 1
3 0001- 52315- 09 n/a Track bolt for swivelling base 1
4 0001- 52315- 07 n/a Retaining screw for swivelling 1
5 0001- 52315- 08 n/a Bolt seat of swivelling baset 1
6 0001- 52315- 03 n/a Swivelling base 1
7 0001- 52315- 02 n/a Tensioning bush for swivelling 1
8 01S1- 16065- 00 n/a Hexagon head cap screw 1
9 0001- 52315- 01 3403003 Threaded bushing for swivelling 1
10 01S1- 12070- 00 6kt.-Schraube Hexagon head cap screw 1
11 0001- 52044- 05 3400222 Face plate 1
FZ
31294
Page 75
