Diamond Products FZ User Manual
Page 49
61
0001- 53854- 03 3400199 Feeding Gear 1
62
0001- 53855- 03 3400580
Travel ring DZ/FZ 1
63
05O1- 00422- 30 3400174
O-ring 1
64
99MS- 54612- 00 3400184 Blade Guard bolt (screw type) 1
Spring Type # 3400762
65
-
-
-
-
-
-
66
-
-
-
-
-
-
67
0001- 54310- 02 3400255 Gasket 1
68
01I1- 06020- 11 3400708 Allen head screw 4
69
99MS- 54565- 01 3400331 Feed Motor 1
70
0001- 53855- 02 3400513 Feeding shaft 1
71
05S2- 00300- 70 3400719 Shaft seal 1
72
02S2- 04717- 50 3400514 Seeger Circlip1
73
04R1- 06906- 00 3400269 Ball bearing 1
74
0001- 54553- 02 3400403 Worm wheel 1
75
02S2- 02110- 50 3400515 Seeger Circlip 1
76
05O1- 00160- 25 3400271
O-ring 1
77
0001- 53854- 06 3400720 Sealing Plug 1
78
04R1- 06906- 00 3400269 Ball bearing 1
79
0002- 53859- 01 3400635 Feed Motor Housing 1
80
01I1- 06060- 00 n/a Allen screw 1
81
99MS- 54565- 01 3400331
Feed Motor 1
82
01I1- 06020- 11 3400708
Allen head screw 4
83
0001- 54310- 02 3400255 Gasket 1
84
0001- 54225- 02 3400519 Sleeve 1
85
0001- 54553- 01 3400402 Worm Gear 1
86
04Z3- 03203- 00 3400516 Ball bearing 1
87
04X1- 00003- 00 3400517 Sheet metal nut 1
88
04W1- 00003- 00 3400518 Spanner nut 1
89
0001- 54310- 03 3400272 Gasket 1
90
0001- 53855- 04 3401872 Gear Housing Cover 1
FZ
31294
Page 49
