5.4 Choosing the saw motor
Choosing the appropriate saw motor results in...
– Best cutting performance
– Least saw blade wear
– Longest working life
:KHQ FKDQJLQJ WKH VDZ EODGH DOZD\V PDNH VXUH WKDW \RX DUH
XVLQJ WKH DSSURSULDWH PRWRU VL]H
Base: Vmin = 38 m/s, Vmax = 42 m/s
Choose the motor like this:
1) Determine the saw blade diameter
2) Note the type of power unit
3) Choose the table with your power
unit in the header
4) Choose the appropriate motor
:KHQ ZRUNLQJ ZLWK OHYHO SRZHU XQLWV DOZD\V ZRUN ZLWK FROXPQ
++ QT JKIJGT :KHQ HQFRXQWHULQJ UHLQIRUFHPHQWV \RX FDQ WKHQ
DOZD\V UNQY FQYP WR WKH QH[W ORZHU OHYHO
FZ + AD-S3 I II III IV
Motor [ccm] Ø min — Ø max Ø min — Ø max Ø min — Ø max Ø min — Ø max
8 - — - - — - - — - - — -
11 - — 500 - — - - — - - — -
16 650 — 700 600 — 650 500 — 550 - — 450
18 750 — 800 650 — 700 550 — 600 450 — 500
22 900 — 1000 800 — 900 650 — 750 550 — 650
25/26 1000 — - 900 — 1000 750 — 800 650 — 700
30/31 1200 — - - — 1200 900 — 1000 800 — 900
40 1600 — 1800 1500 — 1600 1200 — - 1000 — -
50 2000 — 2200 1800 — 2000 1500 — - - — -
FZ + CR-3 I II III IV
Motor [ccm] Ø min — Ø max Ø min — Ø max Ø min — Ø max Ø min — Ø max
8 - — 500 - — - - — - - — -
11 600 — 650 500 — 550 - — - - — -
16 900 — 1000 750 — 800 600 — 650 500 — 550
18 1000 — - 800 — 900 650 — 700 550 — 600
22 1200 — - 1000 — - 800 — 900 650 — 750
25/26 - — 1500 - — - 900 — 1000 750 — 800
30/31 1600 — 1800 - — 1500 - — 1200 900 — 1000
40 2200 — - 1800 — 2000 1500 — 1600 1200 — -
50 - — - - — - 1800 — 2000 1500 — -
Set-up FZ
