5.3 Choosing the saw blade
Select the saw blade with the required diameter with regard to the
requirements both of cut and of technical conditions.
Which saw blades are to be used?
outer Ø: 450 - 2200 mm
inner Ø: 60 mm
Fastening: 6 x M8,
screw hole circle Ø 80mm
Which depth of cut is to be reached?
Table "Depths of cut" shows, which saw blade diameter is to be
selected for a given depth of cut.
Saw blades of a diameter of more than
1000 mm can only be mounted after a
correspondingly deep cut made by a
smaller saw blade.
Which size is the surplus of cut?
Table "Overcut" indicates the required surplus of cut in depend-
ence on saw blade diameter and depth of incision.
Depths of cut
Saw blade
in mm max. depth
of cut LV D SUHYLRXV
LQFLVLRQ
QHFHVVDU\"
450
500
600
750
800
900
1000
12.5
15
20
27.5
30
35
40
PQ
SUHYLRXV
LQFLVLRQ
1200
1500
1600
1800 50
67
72
82 3UHYLRXV LQFLVLRQ
ZLWK VPDOOHU VDZ
EODGH PGEGUUCT[
Example
Door opening in a concrete wall with a thickness of 35 cm:
– The saw blade diameter must be at
least 900 mm
(see table "Depths of cut").
– With maximum depth of incision the
overcut will be 30 cm
(see tabel "Overcut").
Set-up FZ
Page 16 FZ30494E
