Diamond Products FZ - Manual (Page 53)

99MS- 54236- 01 3400252 Carriage Guide Complete Butterfly Handle
1 0001- 53856- 02 3400351 Carrier
2 01I2- 06012- 00 3400103 Allen head screw 8
3 0002- 51974- 01 3400617 Prisma 4
4 02Z1- 04030- 00 3400355 Parallel pin 2
5 0001- 53856- 03 3400352 Shaft 2
6 01I1- 06016- 11 3400346 Allen head screw 8
7 01I4- 05016- 21 3402111 Countersunk head screw 2
8 0001- 53856- 04 3400354 Butterfly Handle 2
9 01G1- 05008- 45 3402110 Set screw 2
10 03T1- 02310- 09 3400357 Disk spring 4
11 0001- 53856- 01 3400353 Holding sleeve 2
FZ
31294
Page 53
