Procedure
Mount wall saw head without saw blade
1) Unscrew adjusting grips completely
2) Mount wall saw head
3) Fasten the adjusting grips so that
there is no play
4) Check between machining for tightly
fastened grips.
5.8 Mounting blade and blade guard
or flush cutting flange
If the saw blade is not mounted
correctly it can get loose and
harm people seriously!
Use only the screws specified for this purpose and meeting the
prescribed length and quality requirements.
When the power unit is running
or even the hoses are under
pressure a blade can start to
turn suddenly and harm people
seriously!
Always turn off and plug out the power unit and relieve the
pressure from the hoses.
Preparations
1) Move the swivel arm to the upper-
most position
2) Mount the saw blade so that the ar-
row points counter-clockwise.
FZ Set-up
