99MM- 34008- __

Saw motor Gr. 3 cpl.

1

07M2- 33208- __ 3401877 (40cc) Hydraulic motor 1

2

0001- 60037- 04 3400583 Motor plate 1

3

01U1- 12020- 50 n/a

Washer 2

4

01S1- 12025- 00 n/a Hex head cap screw 2

5

05O1- 00300- 25 3400306 O-ring 2

6

0001- 53246- 06 3400305 QD Flange 2

7

08D1- 80361- 34 3400276 Sealing ring 3/4" 2

8

14D4- 68492- 34 3401881 3/4" BSP Nipple 2

9

08D1- 80361- 34 3400276 Sealing ring 3/4" 2

10

07S1- 00802- 34 3401023 Coupling FD 1

11

07S1- 00102- 14 3402166 Case Drain Nipple 1

12

08D1- 80301- 14 3400637 Sealing ring 1

13

14D3- 78244- 14 3401100 Double fitting 1

14

07S1- 00801- 34 3401022

Nipple FD

15

01I1- 08050- 00 3400145 Allen head srew 4

16

01I1- 08025- 00 3400606 Allen head srew 4

FZ
31294
