99MS- 54126- 00 Blade protection Ø 800, 3 pc.
1 01I1- 06045- 00 3400921 Allen head srew 8
2 01I1- 06050- 00 2900493 Allen head srew 4
3 0000- 53657- 02 n/a Fixing device
4 0004- 52284- 01 3400397 Aluminium grip 4
5 01I1- 12040- 00 2900408 Allen head srew 2
6 0001- 53646- 11 n/a Screen 1
7 0000- 54129- 01 n/a Center part 1
8 0001- 53646- 09 n/a Scale 1
9 01I4- 04012- 21 n/a Countersunk head srew 6
10 0001- 53646- 05 n/a Roll 6
11 0001- 53646- 06 n/a Flange 6
12 0001- 53646- 07 n/a Distance bush 6
13 01M1- 12000- 00 3402142 Hex nut 6
14 01D2- 06016- 00 n/a Spacer block 1
15 04R3- 06002- RF n/a B all bearing 12
16 0001- 53646- 08 n/a Bolt 6
17 01I1- 05025- 00 n/a Allen head screw 18
18 01U1- 05009- 50 n/a Washer 18
19 99MS- 54208- 00 n/a Splash guard
20 0002- 53659- 02 n/a Fixing device 1
29 99MS- 54126- 90 n/a Lateral part 2
21 01L2- 04012- 00 3400619 Slotted screw 20
22 0003- 53648- 01 3400618 Guiding device 2
23 01I2- 06012- 00 3400103 Allen head screw 8
24 0001- 53661- 01 n/a Connection brace 1
25 0004- 53718- 01 n/a Strap 2
26 01I1- 06008- 00 3400204 Allen head screw 2
27 01N1- 00040- 08 n/a Rivet 24
28 0001- 53661- 03 n/a Connection brace 2
29 0000- 54123- 01 n/a Lateral part 2
30 0004- 53663- 02 n/a Cover 2
