53HC2600 INSTRUCTION MANUAL
82 Menus and Toolbar Buttons
CASCADE
A display presentation of overlapping windows for the control strategy, front panel, and
rear panel displays.
TILE HORIZONTALLY
A display presentation whereby the control strategy, front panel, and rear panel window
displays are stacked one above the other.
TILE VERTICAL
A display presentation whereby the control strategy, front panel, and rear panel window
displays are stacked side-by-side.
ARRANGE ICONS
It causes the icons for the minimized control strategy, front panel, and rear panel window
displays to be arranged in a horizontal row at the bottom of the LoopMaster main window.
TOOLBAR
It is the on/off toggle for the main toolbar.
STATUS BAR
It is the on/off toggle for the main status bar.
