53HC2600 INSTRUCTION MANUAL
Advanced Topics 51
Ai2Type Transmitter type 0 = Unknown, 1 = Self powered, 2 = 2wire
Ai2Line1 First line labeling AI2 rear connection
Ai2Line2 Second line labeling AI2 rear connection
Di1Line1 First line labeling DI1 rear connection
Di1Line2 Second line labeling DI1 rear connection
Di2Line1 First line labeling DI2 rear connection
Di2Line2 Second line labeling DI2 rear connection
Di3Line1 First line labeling DI3 rear connection (if present)
Di3Line2 Second line labeling DI3 rear connection (if present)
Di4Line1 First line labeling DI4 rear connection (if present)
Di4Line2 Second line labeling DI4 rear connection (if present)
Do1Line1 First line labeling DO1 rear connection
Do1Line2 Second line labeling DO1 rear connection
Do2Line1 First line labeling DO2 rear connection
Do2Line2 Second line labeling DO2 rear connection
Do3Line1 First line labeling DO3 rear connection (if present)
Do3Line2 Second line labeling DO3 rear connection (if present)
Do3NO=1 1=Normally Open, 0=Normally Closed
Do4Line1 First line labeling DO4 rear connection (if present)
Do4Line2 Second line labeling DO4 rear connection (if present)
Do4NO=1 1=Normally Open,, 0=Normally Closed
Ao1Line1 Ao1Line1, First line labeling AO1 rear connection
Ao1Line2 Second line labeling AO1 rear connection
Ai3Num Specifies a connection option (e.g. OTD, 3-wire, etc.)
Ai3Line1 First line labeling AI3 rear connection (if present)
Ai3Line2 Second line labeling AI3 rear connection (if present)
Ai4Num=0 Specifies a connection option (e.g. OTD, 3-wire, etc.)
Ai4Line1 First line labeling AI4 rear connection (if present)
Ai4Line2 Second line labeling AI4 rear connection (if present)
Table 6-2. Documenter Section Variables (Continued)
Variable Description
