background image

53HC2600 INSTRUCTION MANUAL

50 Advanced Topics

6.3 LoopMaster File Format

Whenever you perform a File > Save or File > Save As, LoopMaster writes the configuration database
and other information to the .S6D file. The .S6D files are text files and can be viewed by a text editor. The
current version of the LoopMaster software creates three sections in the .S6D file.

6.3.1 [Info] Section

The [Info] section holds information to describe this file and how it will be used by LoopMaster. The first
line of this section is the file description. This section also stores settings for the Characterizer graph axes
if the Characterizer is enabled.

6.3.2 [Documenter] Section

The [Documenter] section holds the text to be used in the Documenter report. Only those lines of text that
have been changed will be written to this section. Here are the entries that may appear in this section:

NOTE

Variables that are not used or have default values do not appear in
the listing.

Table 6-1. Info Section Variables

Variable

Value

Description

Version

a.b

Version a.b

AutoX

1 or 0

CHR graph x-axis autoscaling on when AutoX=1

DivX

1 - 13

Number of x-axis divisions

MaxX

any

Maximum x-axis value

MinX

any

Minimum x-axis value

AutoY

1 or 0

CHR graph autoscaling y-axis autoscaling when AutoY=1

DivY

1 - 13

Number of y-axis divisions

MaxY

any

Maximum y-axis value

MinY

any

Minimum y-axis value

Table 6-2. Documenter Section Variables

Variable

Description

Title1

First line on title page

Title2

Second line on title page

Title3

Third line on title page

Title4

Fourth line on title page

Ai1Type

Transmitter type 0 = Unknown, 1 = Self-powered, 2 = 2-wire

Ai1Line1

First line labeling AI1 rear connection

Ai1Line2

Second line labeling AI1 rear connection
