TABLE 1. F-TRAN OPERATORS
OPERATOR
FUNCTIONS TYPE
"L" "B" "C" "H"
Add + + +
Subtract - - -
Multiply * * *
Divide / / /
Square Root ^
Compare : : :
Expand % % %
Zero Z Z Z
Swap W W W W
Duplicate D D D D
Equal Q
AND & &
OR ’ ’
XOR X X
INVERT ! !
2
X
M
Y
X
P
Contract $ $ $
Log(base 2) V
Abs | |
MODULAR CONTROLLER CUSTOMIZATION GUIDE
2-6
