F-CIM 105
MATH F
NOT REUSABLE
Function:
C S n
0 S n-1
1 C91 * S
n-1
+ C92
2 C91 * S
n-1
+ C92 * A + C93 * B
3 C91 * S
n-1
* A * B + C92
4 C91 ∗Sn−1
A
+ C92*B
5
C91 * S
n-1
+
C92
∗A
B
+ C93
6 C91
∗Sn−1∗
A
B
+ C92
7 C91 +Sn−1
C92
+A
* C93
8 C91 * ABS(S
n-1
) + C92
9 C91 * S n-1
(C92 * A + C93)
10 C91 * 2
(C92 * Sn-1 + C93)
11 C91 * LOG (C92 * S n-1 ) + C93
20 C91 < S n-1 < C92
21 (C92 * B) < S
n-1
< (C93 * A)
Description:
This module provides 12 different mathematical functions. The function to be used is selected
based on the C input.
MODULAR CONTROLLER CUSTOMIZATION GUIDE
3-49
