F-CIM 107
MATH H
NOT REUSABLE
Function:
C S n
0 S n-1
1 C97 * S
n-1
+ C98
2 C97 * S
n-1
+ C98 * A + C99 * B
3 C97 * S
n-1
* A * B + C98
4 C97 ∗Sn−1
A
+ C98*B
5
C97 * S
n-1
+
C98
∗A
B
+ C99
6 C97
∗Sn−1∗
A
B
+ C98
7 C97 +Sn−1
C98
+A
* C99
8 C97 * ABS(S
n-1
) + C98
9 C97 * S n-1
(C98 * A + C99)
10 C97 * 2
(C98 * Sn-1 + C99)
11 C97 * LOG (C98 * S n-1 ) + C99
20 C97 < S n-1 < C98
21 (C98 * B) < S
n-1
< (C99 * A)
Description:
This module provides 12 different mathematical functions. The function to be used is selected
based on the C input.
