Press
Menu

Press Digit Select
Key

Press Value Select
Key

bAtCH

(continued)

_00000

Definition of Item #2

0

Make Item #2 the Grand Total of all batches.

1

Make Item #2 the Total Number of batches.

_00000

Action after Meter Reset

0

Display “rEAdy.” RESET key starts batching.

1

Start batching upon Meter Reset.

_00000

Filter type

0

Adaptive moving average filter. Restarts filter for
high actual changes in signal.

1

Conventional moving average filter without reset.

_00000

Peak & Valley filtering

0

Peak* or Valley* value from unfiltered signal.

1

Peak* or Valley* value from filtered signal.

_00000

Display filtering

0

Display value of unfiltered signal.

1

Display value of filtered signal.

_00000

Adaptive filter threshold

0

Set adaptive filter for normal noise.

1

Set adaptive filter for presence of high transients.

FiLtEr

Filtering

_00000

Filter time constant

0

No filter

1

0.1 sec

2

0.2 sec

3

0.4 sec

4

0.8 sec

5

1.6 sec

6

3.2 sec

7

6.4 sec

.

SLOPE

Triggering

____00

Trigger slope, Channel A

0

Positive slope

1

Negative slope

____00

Trigger slope, Channel B

0

Positive slope

1

Negative slope

dEC.Pt1

Decimal pt1

1

.

11111

Decimal point flashes.

1

.

11111

11

.

1111

111

.

111

1111

.

11

11111

.

1

111111

.

Press to shift the decimal point.

dEC.Pt22

Decimal pt2

2

.

22222

Decimal point flashes.

2

.

22222

22

.

2222

222

.

222

2222

.

22

22222

.

2

222222

.

Press to shift the decimal point.

Scale and Offset scaling method if selected under

SEtuP

SCALE1

Scale
Factor 1

0.00000 0.00000 0.00000
0.00000 0.00000 0.00000

Select digit to flash for
Scale Value. When right
digit flashes, press one
more time for the Scale
Multiplier.

Select

-9

thru

9

for flashing first digit and

0

thru

9

for

other flashing digits. This will set the Scale Value*
from -9.99999 to 9.99999 with a fixed decimal point.
Then press to select a value from

0.00001

to

100000

in decade steps for the Scale Multiplier.

Scale Factor = Scale Value x Scale Multiplier.

OFFSt1

.

Offset 1

000000 000000 000000
000000 000000 000000

Select digit to flash.

Select

-9

thru

9

for flashing first digit and

0

thru

9

for

other flashing digits. Use

dEC.Pt1

to set the decimal

point.

SCALE2

Scale Factor 2. Same setup process as for Scale Factor 1.

OFFSt2

.

Offset 2. Same setup process as for Offset 1.
